Is your Conservatory currently too hot to use?

Is your Conservatory Currently too Hot to Use?

Is your conservatory currently too hot to use? If the answer is yes - we suggest you act now. With temperatures set to soar over the coming weeks, what can you do to keep your conservatory cooler?

Insulate!

Insulating your conservatory roof is the best way to keep it cooler in warm weather and warmer in cold weather. This blog will investigate the Benefits of Insulation and How Simple it is to Install it yourself. [caption id="attachment_27506" align="alignnone" width="292"] An Uninsulated Conservatory on a Sunny Day[/caption]

EcoQuilt Expert Insulation

In Summer EcoQuilt Expert insulation effectively reflects away excess and unwanted heat, and creating a more ambient temperature into your home. Reducing the need for artificial cooling systems and therefore preventing uncomfortable heat build-up in your Conservatory. [caption id="attachment_27507" align="alignnone" width="317"] Ecoquilt Expert Insulation[/caption] EcoQuilt Expert is a Highly Reflective 6 Layer Multifoil Insulation Blanket. It is designed to Insulate Roofs, Walls, Floors, Conservatories, Garden Buildings & Caravans. Also it is suitable for many more applications as it is flexible, thin, and simple to install. It is 15mm thick in its open state and will compress down to approximately 6mm. EcoQuilt is one of the highest performing materials on the market under 10mm.

Why Choose EcoQuilt Expert for Conservatory Roof Insulation?

  • Reflects excess heat out during Summer.
  • Retains heat in during winter.
  • The lightweight nature of EcoQuilt makes it easier to fit by one person.
  • Equivalent to 50mm Rigid PIR Insulation, yet only 15mm Thick – Compresses to 6mm when installed!
  • No protective clothing/handling required.
  • A 6-layer Multifoil to keep heat inside your home and save you money on heating bills.

EcoQuilt Expert Conservatory Kit

Using our EcoQuilt Expert Conservatory Kit is the simplest way to insulate your conservatory roof. The kit is available in 2 different sizes. Our Kit features...
  • EcoQuilt Expert Multifoil Insulation 1.5m x 10m (15m²) OR 2 x 1.5m x 10m (30m²)
  • True Aluminium Thermaseal Foil Joining Tape 75mm x 50m
  • Heavy Duty Staple Gun
  • 5000 x 14mm Staples
  • 200 x FastFix Conservatory Screws 4.8mm x 50mm

How to Install Ecoquilt Expert...

Step 1. Install 25mm deep timber battens onto the UPVC beams. These are screwed onto the beams using 50mm FastFix Conservatory Screws (supplied in the Kit) [caption id="attachment_27512" align="alignnone" width="310"] Initial Batten Installation[/caption]
Step 2. Next, staple the insulation directly onto the battens at 300mm intervals. Ensure all Insulation joints are overlapped by a minimum of 50mm. Ensure overlaps are fully taped and sealed using Thermaseal Foil Joining Tape. Both the Thermaseal Foil Joining Tape and the Staple Gun Kit are supplied in the Kit. [caption id="attachment_27513" align="alignnone" width="318"] Initial Stapling of Insulation[/caption] [caption id="attachment_27514" align="alignnone" width="317"] Fully Taped & Sealed using Foil Joining Tape[/caption] Step 3. Once the Insulation products are fully taped, sealed, and overlapped, proceed with installing 25mm deep counter battens. Ensure battens are also installed around the perimeter for your internal boarding. [caption id="attachment_27515" align="alignnone" width="321"] Secondary Batten Installation[/caption] Step 4. Install ConservaClad cladding to internal of the conservatory roof. ConservaClad is a lightweight cladding which is DIY friendly. Dimensions of ConservaClad are 300mm x 5m. [caption id="attachment_32526" align="alignnone" width="320"]Installing the Conservatory Cladding Installing the ConservaClad Board[/caption]

Before & After Insulation...

We also recommend using the ThermaFrost Tint Kit if you are insulating the underside of a glass conservatory roof. The purpose of a tint is to reduce the UV rays from the sun accessing the cavity between the glass and the reflective foil. This also looks more aesthetically pleasing as you will not see the outer layers of the multifoil through the glass. If you would like a complete quote for ConservaClad & EcoQuilt Expert, please get in touch! So ask yourself, is your Conservatory currently too hot to use? If so, it's time to Insulate it now! Buy our EcoQuilt Expert Conservatory Roof Kit - Here
